Housed Bearing - 2 Bolts
Description
The Housed Bearing - 2 Bolts known as F2B-C-20M-C-P-SS-DFH-SKF SKF has a shaft diameter of 20 mm and a fixing spacing of 90 mm. This part number is produced in FOOD-GRADE POLYPROPYLENE and the tightening type is Eccentric locking ring.
How to read the reference of a housed bearing?
You can find all the information you need about our products in our expert's advice, by clicking here Here
8 to 10 days
Need help or advice?
(646).712.9672
Description
The Housed Bearing - 2 Bolts known as F2B-C-20M-C-P-SS-DFH-SKF SKF has a shaft diameter of 20 mm and a fixing spacing of 90 mm. This part number is produced in FOOD-GRADE POLYPROPYLENE and the tightening type is Eccentric locking ring.
How to read the reference of a housed bearing?
You can find all the information you need about our products in our expert's advice, by clicking here Here
Need help or advice?
(646).712.9672
Brand | SKF |
---|---|
N° EAN13 | 7316577845351 |
Shaft diameter | 20 mm |
No. of fasteners | 2.0000 |
Tightening | Eccentric locking ring |
Mounting center distance | 90 mm |
Material | FOOD-GRADE POLYPROPYLENE |
Weight | 280 g |
Dynamic load | 10,80 kN |
Static load | 6,55 kN |
Packaging | 1 |
Standard | No standard |
The Housed Bearing - 2 Bolts known as F2B-C-20M-C-P-SS-DFH-SKF SKF has a shaft diameter of 20 mm and a fixing spacing of 90 mm. This part number is produced in FOOD-GRADE POLYPROPYLENE and the tightening type is Eccentric locking ring.
How to read the reference of a housed bearing?
Example:
UCF205-SNR
Where
UC = type and shape of bearing
F = type and shape of bearing
205 = housed bearing and bearing dimensions
SNR = manufacturer's markExample N ° 2:
FY50-TF-SKF
Where
FY = Type and shape of the bearing
50 = size identification (diameter of the bore)
TF = type and shape of the bearing
SKF = manufacturer's mark
